| 公称直径DN(mm) | 管程数Number of thbe passes | 管子数量（Pipe number） | 换热面积 trans surface | 管子长度mm pipe length | |||
| 1500 | 2000 | 3000 | 4000 | 6000 | |||
|
159 |
I |
14 |
1.5 |
2 |
3 |
|
|
|
219 |
I |
26 |
3 |
4 |
6 |
8 |
|
|
II |
26 |
3 |
4 |
6 |
8 |
|
|
|
273 |
I |
44 |
5 |
7 |
10 |
14 |
21 |
|
II |
40 |
5 |
6 |
9 |
12 |
19 |
|
|
325 |
I |
60 |
7 |
9 |
14 |
19 |
28 |
|
II |
56 |
6 |
9 |
13 |
17 |
26 |
|
|
400 |
I |
119 |
14 |
18 |
28 |
37 |
55 |
|
II |
110 |
13 |
17 |
26 |
34 |
50 |
|
|
500 |
I |
185 |
|
|
45 |
55 |
85 |
|
II |
180 |
|
|
40 |
55 |
85 |
|
|
600 |
I |
169 |
|
|
60 |
85 |
125 |
|
II |
266 |
|
|
60 |
80 |
125 |
|
|
700 |
I |
379 |
|
|
90 |
120 |
125 |
|
II |
358 |
|
85 |
110 |
165 |
||
|
800 |
I |
511 |
|
|
120 |
160 |
240 |
|
II |
488 |
|
|
115 |
150 |
230 |
|
|
900 |
I |
649 |
|
|
150 |
200 |
305 |
|
II |
630 |
|
|
145 |
195 |
295 |
|
| 1000 | I | 805 | 185 | 250 | 37 | ||
|
II |
792 |
|
|
185 |
245 |
370 |
|
